VSSHP270DV2AS | Jandy ePump Variable Speed Pump | 2.7 HP | SpeedSet Controller
Couldn't load pickup availability
CA P65 Warning: Cancer and reproductive harm. www.p65warnings.ca.gov
- Description
- Additional Info
- Reviews
OEM Jandy ePump Variable Speed Pump VSSHP270DV2AS is a 2.7 HP high-efficiency pool pump engineered for both residential and commercial applications, featuring the pre-installed SpeedSet™ Controller for intuitive operation. Its auto-sensing dual voltage motor (115V/230V) simplifies installation, while the Totally Enclosed Fan-Cooled (TEFC) design ensures quiet, reliable performance. Equipped with two auxiliary relays, it allows for seamless integration with additional pool equipment. The pump boasts a Weighted Energy Factor (WEF) of 7.5/9.3 and includes a large-capacity strainer basket to minimize maintenance. Certified by ENERGY STAR®, it delivers significant energy savings and is compatible with Jandy automation systems.
ePump 2.7 HP, 115/208-230 VAC, 2-Auxiliary Relay Variable-Speed Pump Specifications
-
HP/THP - 2.70 THP
-
WEF - 7.5/9.3
-
Voltage - 208-230/115 VAC
- Carton Weights - 71.5 lbs.
- Port Size - 2" x 2.5"
- Energy Star - Yes
- Motor Type - TEFC
- Phase - 1
- Pool/Spa Application(s) - in-ground
- Port Connections - Unions (Included)
- Professional Installation Required - Yes
- Recommended Pipe Size - 2" to 2.5"
- RPM - Variable
- Smart Product- Automation Compatible (AquaLink RS, AquaLink PDA, AquaLink Z4, JEP-R Pump Controller)
- Strainer Included - Yes
- Watts / AMPS - 208-230V, 2370W, 11.5-10.5A / 115V, 1875W, 16.0A
- Pump Controller - SpeedSet Controller Included
- AUX Relays- 2
ePump 2.7 HP, 115/208-230 VAC, 2-Auxiliary Relay Variable-Speed Pump Features
-
Maximum Savings - Save over $1,100* per year in energy costs! The ePump allows for dramatic energy savings compared to high energy consuming single-speed pumps.
*Based on a 28,000 gallon pool with 2 turnovers per day at an average power cost of 0.195/kWh; when tested in accordance with the applicable requirements of 10 CFR 429. - Less Noise - Bigger does not mean louder. “Quiet Pump“ technology controls flow dynamics within the pump, resulting is less hydraulic noise — allowing you to simply enjoy a peaceful day by your pool.
- Better Performance - Small pump baskets fill faster — restricting flow and eroding performance. The ePump features the largest capacity smooth surface basket in the industry for reduced maintenance and improved performance.
- Pool Control in the Palm of Your Hand - Take control of your pump, whether at home or on the go. When paired with iQPUMP01 or a Jandy Aqualink® Automation system the ePump offers anytime, anywhere control of your pump with iAquaLink — the highest-rated pool control app.
- Multiple Control Options - The ePump is completely programmable and customizable with the Jandy® AquaLink® line of automation systems, iQPUMP01, or the JEP-R controller (controller sold separately).
- Maximum Convenience - Featuring two auxiliary relays which, when combined with iQPUMP01, enables instant automation for your pump — plus two additional pieces of equipment — eliminating the need for an extra timeclock to control equipment such as a booster pump or salt chlorinator.
- 115v/230v Dual Voltage - Auto-sensing dual voltage variable-speed motor automatically recognizes and adapts to 115- or 230-volt power supplies, providing installation flexibility and eliminating the need for expensive main power rewiring.
-
Power All Your Features
With excellent hydraulic performance, the applications are endless. From filtration to negative edges and everything in between—waterfalls, water features and spa jets.
-
Fast, Simple Setup
Quick and intuitive, the optional SpeedSet™ Controller allows you to quickly set up and program the ePump, making installation and maintenance a breeze.
-
Better Performance
Small pump baskets fill faster — restricting flow and eroding performance. The ePump helps reduce maintenance and improve performance with the largest-capacity, smooth-surface basket in the industry.
-
Two Programmable Auxiliary Relays for Instant Automation
Two programmable auxiliary relays allow the pump to control other equipment, such as a salt chlorinator and booster pump, without a separate timeclock.
-
No Rewiring Necessary
Auto-sensing dual voltage motor automatically recognizes and adapts to 115 or 230-volt power supplies.
-
Additional Features
Available in 2.2 and 2.7 HP models.
RS485 Quick Connect Port for faster installation maintenance.
Four-Speed Dry Contact Relay Control.
East controller setup auto detects connection to an automation system or a traditional controller, eliminating the need to adjust settings manually.
2" x 2.5" unions included / 2.5" x 3" compatible.
Ergonomic carry handle for easy installation.
Tool free lid allows quick and easy cleaning of the pump basket.
Zero Clearance Totally Enclosed Fan-Cooled permanent magnet brushless DC motor that provides cooler operation and extended motor life. -
Choose Your Own Controller
Designed to work with the following Jandy control systems for complete programmability and costumization:SpeedSet Controller (included and preinstalled from factory on all DV2AS models).
iQPUMP with iAquaLink App Control.
Jandy AquaLink Automation Systems.
JEP-R Controller.
Highlights
-
High-Efficiency Motor: 2.7 HP TEFC motor delivers quiet and reliable performance
-
Dual Voltage Capability: Auto-sensing 115V/230V motor simplifies installation
-
Integrated Automation: Two auxiliary relays for controlling additional equipment
-
User-Friendly Controller: SpeedSet™ Controller offers intuitive operation
- Energy Star Certified: Delivers significant energy savings with a WEF of 7.5/9.3
Jandy ePump 2.7 HP Variable-Speed Pump | Model VSSHP270DV2A
The Jandy ePump VSSHP270DV2A delivers premium energy savings and ultra-quiet operation for medium to large in-ground pools and spas. With its variable-speed motor and dual-voltage compatibility, it offers flexible installation, automation-ready integration, and powerful, efficient performance that can save homeowners up to $1,100 annually in energy costs.
Industry-Leading Energy Efficiency
Save Over $1,100 Annually
Outperforms traditional single-speed pumps with significant cost savings.
Dual Voltage with Auto-Sensing
Automatically detects and adjusts to 115V or 230V power input—no rewiring needed.
Energy Star® Compliant
Delivers top-tier efficiency to meet modern energy standards.
Quiet, Reliable Operation
Quiet Pump Technology
Proprietary sound-dampening motor runs no louder than a refrigerator.
Extended Motor Life
Zero-clearance TEFC motor design runs cooler and resists environmental wear.
Oversized Basket & Smart Features
Industry’s Largest Debris Basket
Smooth interior design for reduced clogging and fewer cleanouts.
Tool-Free Basket Lid
Allows for quick and easy maintenance access.
Built for Smart Automation
Two Programmable Auxiliary Relays
Control other pool equipment like salt systems or booster pumps directly.
RS485 Quick Connect Port
Simplifies installation with automation systems such as AquaLink® or iQPUMP01.
Installation & Customization
Ergonomic Carry Handle
Makes setup and repositioning easier for installers.
Flexible Union Compatibility
Includes 2" x 2.5" unions; compatible with 2.5" x 3" plumbing.
Easy Controller Integration
Auto-detects connection with Jandy automation or traditional controllers.
Compatible Control Systems
SpeedSet Controller
Factory-installed on all DV2AS models for fast and easy speed adjustments.
iQPUMP with iAquaLink App
Wireless control via smartphone or tablet.
AquaLink Automation & JEP-R
Seamless integration with Jandy automation platforms for total control.
