The Jandy Levolor K1100CKC Pool Water Leveler with 100′ sensor and 1″ solenoid valve automatically maintains a consistent water level by detecting low-water conditions and refilling to a pre-set level. Designed for pools, spas, and water features, it employs advanced electronic monitoring to ensure accuracy and dependability. Unlike mechanical devices, it has no moving parts to wear out, eliminating concerns of rust or mechanical failure. With wave compensation and an exclusive lock-out feature to prevent overfilling, the Levolor delivers worry-free water management for both new and existing installations.
-
Automatic Water Level Control: Detects low-water conditions and refills automatically to a programmed level, reducing manual maintenance and preventing equipment damage.
-
Advanced Electronic Monitoring: Uses sophisticated electronics to ensure precise control, compensating for surface movement and preventing false fills caused by waves.
-
Exclusive Lock-Out Feature: Built-in safety function prevents overfilling, protecting your pool, spa, or water feature from unnecessary water waste or overflow.
-
Durable, Maintenance-Free Design: With no moving parts to rust, break, or jam, the Levolor ensures long-lasting, reliable performance in harsh pool environments.
-
Flexible for Any Installation: Suitable for both new builds and retrofits, and includes a 100′ sensor cable and 1″ solenoid valve for versatile applications.
-
Pool/Spa Application(s): in-ground and above-ground
-
Retrofit: Yes
-
Input Current: 110/220 VAC, 50/60 HZ, 0.5 AMPS
-
Output: 24 VAC @ 1 AMP
-
Maximum Working Pressure: 125 PSI
-
Sensor Lead: 100 ft.
-
Sensor Style: Dual Style
-
Solenoid Valve: 1"
-
Bodies of Water: Single body
-
Application: Pool or spa
