46611 | Hayward PureWhite PR2 LED Pool Lamp | 2800Lm - 2700K Warm White
Pickup, delivery and shipping times are estimates, not guarantees.
Couldn't load pickup availability
● 88 in stock30-day returns Secure checkout
Have a question about this part?
Ask about fit, specs or shipping and get an instant answer.
Goes with this part
CA P65 Warning: Cancer and reproductive harm. www.p65warnings.ca.gov
The J&J Electronics PureWhite Pro LED Pool Lamp (Model 46611) delivers vibrant warm-white illumination (2,800 lumens at 2,700 K color temperature) in a retrofit Edison-base format for in-ground pools and spas. Engineered as a direct-fit replacement for traditional incandescent pool lights, it significantly reduces energy usage and maintenance needs while delivering crisp, consistent lighting. This lamp installs easily into most standard fixtures, includes the Guardian™ replacement lens gasket tailored for LED service, and supports seamless operation across major pool automation platforms.
-
High-Output Warm White Illumination: Generates approximately 2,800 lumens at a 2,700 K warm white tone, offering a premium lighting experience in your pool or spa environment.
-
Edison-Base Retrofit Design: Fits most existing in-ground pool light housings via standard Edison screw base, making installation straightforward without major rewiring.
-
Energy-Efficient LED Technology: LED design substantially slashes energy consumption compared to equivalent 100 W-500 W incandescent lamps, lowering utility costs and extending service life.
-
Uniform Beam & Long Life: Features a “zero-pixelation” lens and wide beam spread for smooth, consistent lighting across surfaces, and offers a lifespan of over 40,000 hours.
-
Complete Retrofit Kit: Includes the specific Guardian™ lens gasket designed for LED use, avoids compatibility issues, and integrates easily with most automation and control systems.
-
Application - Lighting: Pools
-
Brand: Hayward
-
OmniDirect Compatible: No
-
Parts Warranty: 1-year
-
Pool Type: Commercial, In Ground
-
Series Lighting: PureWhite Pro LED Lamps
-
Sub Brand: J & J Lighting
-
Voltage - Lighting: 120V
-
Watts: 39 W
-
Lumen Output (Brightness): 2800
