AquaStar Flow Star SKR1xx Skimmer Replacement Parts Diagram

Interactive parts diagram

10 parts. Tap a number on the diagram, or search by part number.

 – exploded view with numbered parts

Scroll or pinch to zoom · drag to move

    • Not sold online AquaStar Flow Star skimmer body (SKR1xx) Call us and we'll get it for you.
    • Not sold online AquaStar 2" port plug Call us and we'll get it for you.
    • Not sold online AquaStar adjustable round skimmer collar SK5xxxCall us and we'll get it for you.
  1. Color
    • Not sold online AquaStar plaster shield Call us and we'll get it for you.

Don't see your part? Ask us and we'll find it.

Also fits your AquaStar Flow Star SKR1xx Skimmer

Not shown on the diagram, but made for this pump.

Fit guide

Which Flow Star part fits?

Part numbers come from AquaStar's Flow Star skimmer (SKR1xx) spec sheet and skimmer accessory pages. The last three digits are the color.

Round skimmer lid (item 7)

White
RT101
Light gray
RT103

Colors: 101 white, 102 black, 103 light gray, 105 dark gray, 108 tan.

Inside the skimmer

Basket with rod items 4-5
SK6
9" Ultra basket -L models
SK96
Float assembly item 3
SKFL101
Weir with clips item 9
SKWD101
Weir clips only item 10
SK902

Other options

Vacuum plate
SK43101
3" extension collar
SECxxx
Square lid and collar
SK64xxx
Snap-in round/square lid and collar
SK65xxx
